When launching a new Carbone instance, you need only to configure the followings option when starting the EC2 instance :

• configure EC2 Security Group to accept at least inbound connections TCP/4000.
• assign AWSMarketplaceMeteringFullAccess role to ec2 instance

When EC2 is fully booted, you can check if Carbone is running by calling : http://"EC2_IP":4000/status

Full API documentation is available here: https://carbone.io/documentation/developer/http-api/introduction.html

Full documentation is available here : https://carbone.io/documentation/developer/self-hosted-deployment/deploy-on-aws.html

You can configure Carbone application by modifying /var/www/carbone-ee/config/config.json. To connect to the EC2 instance, use SSH and the username ec2-user with your private key.

Full Carbone options documentation : https://carbone.io/documentation/developer/on-premise-installation/configuration.html

It's now possible to fully configure Carbone without modifying config.json file.

To make it possible, you first need to add following policy to grant configuration access for Carbone { "Version": "2012-10-17", "Statement": [ { "Effect": "Allow", "Action": "ssm:GetParameter", "Resource": "" }, { "Effect": "Allow", "Action": "ssm:DescribeParameters", "Resource": "" }, { "Effect": "Allow", "Action": [ "ec2:DescribeTags" ], "Resource": [ "*" ] } ] }

Next step is to set configuration in System Manager https://console.aws.amazon.com/systems-manager/parameters/

You can now configure Carbone standard option with : CARBONE_EE_* (CARBONE_EE_STUDIO to true to enable studio) CARBONE_EE_STUDIO CARBONE_EE_STUDIOUSER .... CARBONE_S3_* to configure S3 options: CARBONE_S3_templateS3Bucket CARBONE_S3_templateS3BucketRegion .... CARBONE_PUBKEY to set Carbone publikey (for authentification)

If you need to manage multiple Carbone configuration for different environnement, you can set instance TAG to configure config prefix: CARBONE_CONFIG_PREFIX= "/PROD/" for example

You can configure CARBONE_EE_STUDIO to true in AWS System Manager

You can set bucket name and region in file /var/www/carbone-ee/config/config.json with the following options: "templateS3Bucket" : "test-stockage-template", "templateS3BucketRegion" : "us-east-1", "templateS3Folder" : "prod", "renderS3Bucket" : "test-stockage-render", "renderS3Folder" : ""

Authentification is done using EC2 IAM role so you need to add following policy to grant S3 access to you EC2 instance : { "Version": "2012-10-17", "Statement": [ { "Sid": "VisualEditor0", "Effect": "Allow", "Action": [ "s3:PutObject", "s3:GetObject", "s3:GetObjectAttributes", "s3:ListBucket", "s3:DeleteObject" ], "Resource": [ "arn:aws:s3:::test-stockage-template", "arn:aws:s3:::test-stockage-template/", "arn:aws:s3:::test-stockage-render", "arn:aws:s3:::test-stockage-render/" ] } ] }

You only need to attach *CloudWatchAgentServerPolicy on EC2 IAM role to enable Carbone logs export in CloudWatch

All customers data are stored in /var/www/carbone-ee/ folder. Only the template are persistent. By defaut API authentification is disable but you can enable it : https://carbone.io/on-premise.html#server-authentication
